09043326831

Teknik Özellikler

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ambalaj

Bulk

Contact Finish

Gold

Style

D

Reliability

COMMERCIAL

Length Termination

0.177 inch

Özellikler

Mounting Clips

Mixed Contacts

NO

Flammability Rating

UL94 V-0

Material Insulation

Thermoplastic, Glass Filled

ECCN Kodu

EAR99

Parça Durumu

Active

Number Of Pcb Rows

2

Option

GENERAL PURPOSE

Total Number Of Contacts

32

Durability

400 Cycles

Body Length Or Diameter

3.736 inch

Dielectric Withstanding Voltage

1000VAC V

Empty Shell

NO

Operating Temperature Min

-55°C

Mil Conformance

NO

Fabrika Tedarik Süresi

16 Weeks

Connector Type

Receptacle, Female Sockets

Kurşunsuz Kodu

yes

Terminal

Solder

Pozisyon Sayısı

32 (Power)

Body Depth

0.457 inch

Reference Standard

UL

Name Of Rows Loaded

A,C

Number Of Positions Loaded

All

Material Flammability Rating

UL94 V-0

Montaj

Panel, Through Hole

Din Conformance

YES

Iec Conformance

NO

Montaj Tipi

Panel Mount, Through Hole

Insulation Resistance

10000000000Ohm

RoHS Durumu

ROHS3 Compliant

Pcb Contact Pattern

RECTANGULAR

Rated Current Signal

6A

HTS Kodu

8536.69.40.40
