09042327832

Teknik Özellikler

Ul Flammability Code

94V-0

Seri

DIN 41612

Sıra Sayısı

2

Pcb Contact Row Spacing

5.08 mm

Pozisyon Sayısı

32 (Power)

Fabrika Tedarik Süresi

11 Weeks

Connector Type

Receptacle, Female Sockets

Number Of Positions Loaded

All

Body Depth

0.457 inch

Din Conformance

YES

RoHS Durumu

ROHS3 Compliant

Insulation Resistance

1000000000000Ohm

Pin Sayısı

32

Total Number Of Contacts

32

Insertion Forcemax

1.5568 N

Level Class

3

Durability

50 Cycles

Contact Materials

Gold, Nickel

Reach Svhc

No SVHC

Akım Değeri

6A

Mil Conformance

NO

Operating Temperature Min

-65°C

Dielectric Withstanding Voltage

1550VAC V

Empty Shell

NO

Style

D

Nem Hassasiyeti (MSL)

1 (Unlimited)

Reliability

COMMERCIAL

Flammability Rating

UL94 V-0

Mixed Contacts

NO

Option

GENERAL PURPOSE

Contact Resistance

15MOhm

Rated Current Signal

6A

Test Voltage

1.55kV

Pcb Contact Pattern

RECTANGULAR

Body Breadth

0.417 inch

Filter Feature

NO

Pitch

0.200 5.08mm

Terminal

Solder

Kurşunsuz Kodu

yes

Name Of Rows Loaded

A,C
