09042326826

Teknik Özellikler

Material Insulation

Thermoplastic, Glass Filled

Number Of Pcb Rows

2

Parça Durumu

Active

Number Of Contacts

216

Ambalaj

Bulk

Contact Finish

Gold

Length Tail

3mm

Material Flammability Rating

UL94 V-0

Montaj

Through Hole

Iec Conformance

NO

Gender

Receptacle

Montaj Tipi

Through Hole

Kurşunsuz Kodu

yes

Onay Kuruluşu

IEC

Uzunluk

94.9mm

Terminal

Solder

Name Of Rows Loaded

A,C

Housing Material

Thermoplastic

Filter Feature

NO

Pitch

0.200 5.08mm

Pcb Contact Pattern

RECTANGULAR

Rated Current Signal

6A

Body Breadth

0.417 inch

Kurşunsuz

Lead Free

Flammability Rating

UL94 V-0

Mixed Contacts

NO

Contact Resistance

15mOhm

Option

GENERAL PURPOSE

Nem Hassasiyeti (MSL)

1 (Unlimited)

Style

D

Reliability

COMMERCIAL

Max Current Rating

6A

Empty Shell

NO

Dielectric Withstanding Voltage

1550VAC V

Mil Conformance

NO

Akım Değeri

6A

Durability

400 Cycles

Insertion Forcemax

1.5568 N

Min. Çalışma Sıcaklığı

-55°C

Din Conformance

YES
