09042326821

Teknik Özellikler

Material Flammability Rating

UL94 V-0

Montaj

Panel, Through Hole

Hole Diameter

1 mm

Working Voltage

125V

Montaj Tipi

Panel Mount, Through Hole

Gender

Receptacle

Iec Conformance

NO

Uzunluk

94.9mm

Kurşunsuz Kodu

yes

Terminal

Wire Wrap

Name Of Rows Loaded

A,C

Housing Material

Thermoplastic

Filter Feature

NO

Pitch

0.200 5.08mm

Test Voltage

1.55kV

Pcb Contact Pattern

RECTANGULAR

HTS Kodu

8536.69.40.40

Rated Current Signal

6A

Body Breadth

0.417 inch

Material Insulation

Thermoplastic, Glass Filled

ECCN Kodu

EAR99

Number Of Contacts

32

Number Of Pcb Rows

2

Parça Durumu

Active

Contact Finish

Gold

Ambalaj

Bulk

Depth

10.5mm

Length Tail

20mm

Min. Çalışma Sıcaklığı

-65°C

Lead Pitch

5.08mm

Din Conformance

YES

Insulation Resistance

1000000000000Ohm

RoHS Durumu

ROHS3 Compliant

Fabrika Tedarik Süresi

4 Weeks

Connector Type

Receptacle, Female Sockets

Pozisyon Sayısı

32 (Power)

Orientation

Straight

Maks. Çalışma Sıcaklığı

125°C

Number Of Positions Loaded

All

Sıra Sayısı

2
