09034646825

Teknik Özellikler

Sıra Sayısı

3

Seri

DIN 41612

Filter Feature

NO

Pitch

0.100 2.54mm

Ul Flammability Code

94V-0

Rated Current Signal

2A

Montaj

Through Hole

Material Flammability Rating

UL94 V-0

Min. Çalışma Sıcaklığı

-55°C

Montaj Tipi

Through Hole

Iec Conformance

NO

Din Conformance

YES

Gender

Female

Insulation Resistance

1000000000000Ohm

Polarization Key

ENDS

Contact Plating

Gold

RoHS Durumu

ROHS3 Compliant

Uzunluk

94.9mm

Fabrika Tedarik Süresi

9 Weeks

Kurşunsuz Kodu

yes

Connector Type

Receptacle, Female Sockets

Orientation

Straight

Pozisyon Sayısı

96

Terminal

Solder

Maks. Çalışma Sıcaklığı

125°C

Name Of Rows Loaded

A,C

Number Of Positions Loaded

64

Housing Material

Thermoplastic

Max Current Rating

2A

Akım Değeri

2A

Mil Conformance

NO

Total Number Of Contacts

64

Level Class

2

Material Insulation

Thermoplastic, Glass Filled

Flammability Rating

UL94 V-0

Mixed Contacts

NO

ECCN Kodu

EAR99

Contact Resistance

20mOhm

Option

GENERAL PURPOSE

Number Of Pcb Rows

3
