09032966825

Teknik Özellikler

Filter Feature

NO

Pitch

0.100 2.54mm

Test Voltage

1kV

Rated Current Signal

2A

Working Voltage

250V

Hole Diameter

1 mm

Montaj

Through Hole

Material Flammability Rating

UL94 V-0

Iec Conformance

NO

Gender

Receptacle

Montaj Tipi

Through Hole

Kurşunsuz Kodu

yes

Uzunluk

10.5mm

Onay Kuruluşu

IEC

Terminal

Solder

Housing Material

Thermoplastic

Length Tail

4.5mm

Material Insulation

Thermoplastic, Glass Filled

ECCN Kodu

EAR99

Number Of Pcb Rows

3

Parça Durumu

Active

Ambalaj

Bulk

Depth

10.5mm

Sıra Sayısı

3

Seri

DIN 41612

Ul Flammability Code

94V-0

Voltage Rated Dc

250V

Min. Çalışma Sıcaklığı

-55°C

Din Conformance

YES

Lead Pitch

2.54mm

Polarization Key

ENDS

Insulation Resistance

1000000000000Ohm

RoHS Durumu

ROHS3 Compliant

Contact Plating

Gold

Connector Type

Receptacle, Female Sockets

Fabrika Tedarik Süresi

9 Weeks

Maks. Çalışma Sıcaklığı

125°C

Orientation

Straight

Pozisyon Sayısı

96

Number Of Positions Loaded

All
