09032646421

Teknik Özellikler

Number Of Pcb Rows

2

Genişlik

95mm

Option

GENERAL PURPOSE

Material Flammability Rating

UL94 V-0

Reach Svhc

No SVHC

Contact Resistance

20mOhm

Parça Durumu

Active

Flammability Rating

UL94 V-0

Mixed Contacts

NO

Orientation

Straight

RoHS Durumu

ROHS3 Compliant

Maks. Çalışma Sıcaklığı

125°C

Pitch

0.100 2.54mm

Material

Thermoplastic

Min. Çalışma Sıcaklığı

-55°C

Housing Material

PBT

Pozisyon Sayısı

96

Filter Feature

NO

Material Insulation

Thermoplastic, Glass Filled

Insulation Resistance

1 TΩ

Gender

Receptacle

Contact Finish

Gold

Ambalaj

Bulk

Lead Pitch

2.54mm

Total Number Of Contacts

64

Connector Type

Receptacle, Female Sockets

Pcb Contact Row Spacing

5.08 mm

Style

C

Level Class

2

Akım Değeri

2A

Number Of Positions Loaded

64

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Conductors

ONE

Iec Conformance

NO

Seri

DIN 41612

Mil Conformance

NO

Montaj Tipi

Through Hole

Kurşunsuz Kodu

yes

Contact Materials

Copper

Din Conformance

YES
