09032606805

Teknik Özellikler

Kurşunsuz

Lead Free

Mating Contact Row Spacing

0.1 inch

Sıra Sayısı

3

Fabrika Tedarik Süresi

8 Weeks

Terminal

Solder

Din Conformance

YES

Connector Type

Receptacle, Female Sockets

Gender

Receptacle

Ambalaj

Bulk

Rated Current Signal

2A

Insulation Resistance

1000000000000Ohm

Seri

DIN 41612

Nem Hassasiyeti (MSL)

1 (Unlimited)

Pcb Contact Pattern

RECTANGULAR

Style

M

Pitch

0.100 2.54mm

Pozisyon Sayısı

64 (60 + 4 Coax, Fiber Optic or Power)

Housing Material

Thermoplastic

Parça Durumu

Active

Contact Plating

Gold

Number Of Pcb Rows

3

RoHS Durumu

ROHS3 Compliant

Orientation

Straight

Operating Temperature Min

-65°C

Mil Conformance

NO

Montaj Tipi

Through Hole

Depth

10.5mm

Number Of Contacts

64

Montaj

Through Hole

Max Current Rating

2A

Kurşunsuz Kodu

yes

Contact Materials

NOT SPECIFIED

Name Of Rows Loaded

A,B,C

Lead Pitch

2.54mm

Ul Flammability Code

94V-0

Polarization Key

POLARIZED HOUSING

Iec Conformance

NO

Akım Değeri

2A

Number Of Positions Loaded

60

JESD-609 Kodu

e4
