Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Physical Dimension
- 28mm x 5mm x 15mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ambient Temperature Range High
- 85°C
- Coil Voltage Dc
- 24V
- Seri
- 34
- Seal Rating
- Sealed - Flux Protection
- Operate Time
- 5ms
- Ambalaj
- Bulk
- Coilresistance
- 3.35kOhm
- Akım Değeri
- 6A
- Reference Standard
- CSA; PCT; RINA; UL; VDE
- Kontak Formu
- SPDT (1 Form C)
- Contact Ac Max Rating R Load
- 10A@400VAC
- Coil Current
- 7.1mA
- Coil Voltage
- 24VDC
- Coil Power
- 170mW
- Switching Voltage
- 400VAC -Max
- Contactoutput Supply Type
- AC/DC
- Fabrika Tedarik Süresi
- 6 Weeks
- Must Operate Voltage
- 16.8VDC
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 24V
- Relay Type
- General Purpose
- Contact Voltageacmax
- 400V
- Onstate Resistance
- 3.35kOhm
- Dielectric Strength Between Open Contacts
- 1500 Vrms
- Contact Currentacmax
- 10A
- Terminal Stili
- PC Pin
- Pcb Hole Count
- 5
- Dielectric Strength Between Coil And Contacts
- 4000 Vrms
- Coilinput Supply Type
- DC
- Çalışma Sıcaklığı
- -40°C~85°C
- Release Time
- 3ms
- Electricallife
- 60000 Cycle(s)
- Genişlik
- 28mm
- Voltage Rated Ac
- 250V
- Power Rating
- 1.5kW
- Yükseklik
- 15mm
- Contact Materials
- Silver Nickel (AgNi)
