100DP1T1B1M2QEH

Teknik Özellikler

Max Voltage Rating Ac

250V

Actuator Material

Brass, Chrome Plated

Çalışma Sıcaklığı

-30°C~85°C

Bushing Thread

1/4-40

Parça Durumu

Active

Illumination

Non-Illuminated

Illumination Type

Illuminated, Non-Illuminated

Terminal Stili

PC Pin

Orientation

Straight

Contact Current Rating

5A

Kurşunsuz

Lead Free

Yayın Yılı

2007

RoHS Durumu

ROHS3 Compliant

Contact Materials

Silver

Panel Cutout Dimensions

Circular - 6.35mm Dia

Ambalaj

Bulk

Actuator Type

Standard Round

JESD-609 Kodu

e4

Kurşunsuz Kodu

yes

Terminal

PC Pin

Voltage Rated Ac

120V

Circuit

DPDT

Montaj

Panel

Fabrika Tedarik Süresi

7 Weeks

Montaj Tipi

Panel Mount

Voltage Rated Dc

28V

ECCN Kodu

EAR99

Switch Function

On-On

Akım Değeri

5A

Electricallife

40,000 Cycles

Seri

100

Özellikler

Epoxy Sealed Terminals

Max Voltage Rating Dc

28V

Nem Hassasiyeti (MSL)

1 (Unlimited)

Reach Svhc

No SVHC

Switch Type

TOGGLE SWITCH

Actuator Length

10.41mm

Current Rating Amps

5A AC/DC
