1003P1T1B1M1REH

Teknik Özellikler

Montaj Tipi

Panel Mount

Switch Function

On-On

Ambalaj

Bulk

Center Contact Plating

GOLD OVER NICKEL

Contact Resistance

0.01mOhm

Housing Material

STAINLESS STEEL

Voltage Rated Ac

20V

Seri

100

Yüzey Montaj

NO

Bushing Length

0.35 inch

Özellikler

Epoxy Sealed Terminals

Body Height

10.6934mm

Terminal Stili

Solder Lug

ECCN Kodu

EAR99

Panel Cutout Dimensions

Circular - 6.35mm Dia

Bushing Thread

1/4-40

Body Breadth

12.7 mm

End Contact Material

COPPER ALLOY

Insulation Materials

DIALLYL PHTHALATE

Illumination

Non-Illuminated

Nem Hassasiyeti (MSL)

1 (Unlimited)

Parça Durumu

Active

Fabrika Tedarik Süresi

10 Weeks

Actuator Type

Standard Round

Circuit

3PDT

Actuator Length

10.41mm

Yayın Yılı

2006

Terminal Material

COPPER ALLOY

RoHS Durumu

ROHS3 Compliant

End Contact Plating

GOLD OVER NICKEL

Çalışma Sıcaklığı

-30°C~85°C

Actuator Material

Brass, Chrome Plated

Electricallife

40,000 Cycles

Body Length Or Diameter

16.51mm

Center Contact Material

COPPER ALLOY

Current Rating Amps

0.4VA AC/DC

Switch Type

TOGGLE SWITCH
