Adet bazlı fiyat
- 1+ adet$0.27
- 10+ adet$0.25
- 100+ adet$0.24
- 500+ adet$0.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Operating Temperature Max
- 150°C
- Terminal Sayısı
- 3
- Ambalaj
- Tape & Reel (TR)
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Number Of Phases
- 1
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Reverse Currentmax
- 100μA
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Surface Mount
- Current Reverse Leakage Vr
- 100μA @ 100V
- Output Currentmax
- 8A
- Diode Element Material
- SILICON
- Additional Feature
- FREE WHEELING DIODE
- REACH Uyumluluk Kodu
- not_compliant
- Terminal Pozisyonu
- DUAL
- Yüzey Montaj
- YES
- Voltage Dc Reverse Vr Max
- 100V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Current Average Rectified Io
- 8A
- Kılıf / Paket
- PowerDI™ 5
- Terminal Formu
- FLAT
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- JESD-609 Kodu
- e3
- Jesd30 Code
- R-PDSO-F3
- Rep Pk Reverse Voltagemax
- 100V
- Configuration
- SINGLE
- Number Of Elements
- 1
- Diode Type
- Schottky
- Operating Temperature Junction
- -55°C~150°C
- Applications
- FAST SOFT RECOVERY
- Nonrep Pk Forward Currentmax
- 150A
- HTS Kodu
- 8541.10.00.80
- Case Connection
- CATHODE
- Voltage Forward Vf Max If
- 700mV @ 8A
- Fabrika Tedarik Süresi
- 14 Weeks
- Terminal Kaplaması
- Matte Tin (Sn)
