GRB263A101RN1D

Teknik Özellikler

Actuator Marking

No Marking

Illumination Type

Illuminated, LED

Dielectric Withstanding Voltage

1500VAC V

Montaj

Panel, Snap in

Insulation Resistance

100000000Ohm

Housing Material

NYLON

Contact Ac Max Rating R Load

10A@277VAC

Body Length Or Diameter

36.3982mm

Seri

GRB

Ambalaj

Bulk

Body Height

28.194mm

Color Actuatorcap

Black

Panel Cutout Dimensions

Rectangular - 36.60mm x 21.20mm

Parça Durumu

Active

Length Termination

0.39 inch

Contact Resistance

0.05mOhm

RoHS Durumu

ROHS3 Compliant

Akım Değeri

21A

Mechanical Life

100,000 Cycles

Current Rating Amps

16A AC 21A DC

Terminal

Quick Connect

Actuator Material

GLASS FILLED NYLON

Montaj Tipi

Panel Mount, Snap-In

Çalışma Sıcaklığı

-20°C~85°C

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Ac Max Power Rating R Load

0.75HP@277VAC

Actuator Length

0.303 inch

Actuator Type

Concave (Curved) - Illuminated

Switch Function

On-Off

Voltage Rated Dc

14V

Illumination Type Color

LED, Red

Body Breadth

20.701 mm

Contact Voltageacmax

277V

Voltage Rated Ac

125V

Contact Currentacmax

10A

Circuit

SPST

Switch Type

ROCKER SWITCH

Terminal Material

BRASS

Illumination Color

Red

Terminal Stili

Quick Connect - 0.250 (6.3mm)
