Adet bazlı fiyat
- 1+ adet$0.84
- 10+ adet$0.79
- 100+ adet$0.75
- 500+ adet$0.70
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Ac Max Rating R Load
- 0.5A@125VAC
- Voltage Rated Dc
- 125V
- Switch Function
- On-On
- Body Height
- 7.239mm
- Contact Currentdcmax
- 0.5A
- Ambalaj
- Bulk
- Actuatorcolor
- BLACK
- Contact Resistance
- 0.01mOhm
- Termination Type
- SOLDER
- Contact Finish
- Silver
- Mounting Feature
- THROUGH HOLE-STRAIGHT
- Length Termination
- 0.438 inch
- RoHS Durumu
- ROHS3 Compliant
- Contact Function
- ON-ON
- Montaj
- Panel
- Risk Rank
- 5.77
- Montaj Tipi
- Panel Mount
- Contact Currentacmax
- 0.5A
- Actuator Length
- 11.50mm
- Contact Voltagedcmax
- 125 V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Ac
- 125V
- Contact Dc Max Rating R Load
- 0.5A@125VDC
- Çalışma Sıcaklığı
- -10°C~104°C
- Part Life Cycle Code
- Active
- Mechanical Life
- 10,000 Cycles
- Terminal Length
- 0.438 inch
- Actuator Type
- Standard
- RoHS
- Yes
- Actuator Material
- Polyamide (PA66), Nylon 6/6
- Fabrika Tedarik Süresi
- 12 Weeks
- Seri
- GF
- Contact Materials
- Copper
- Current Rating Amps
- 500mA AC/DC
- Yüzey Montaj
- NO
- Operating Temperaturemax
- 104 °C
- Terminal Stili
- PC Pin
- Pozisyon Sayısı
- 1
- Housing Material
- COLD ROLLED STEEL
- Terminal Material
- COPPER
