Adet bazlı fiyat
- 1+ adet$9.29
- 10+ adet$8.76
- 100+ adet$8.26
- 500+ adet$7.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mating Contact Pitch
- 0.108 inch
- Shell Size Connector Layout
- 4 DC C
- Rated Current Signal
- 1A
- Dielectric Withstanding Voltage
- 500VDC V
- Contact Materials
- Phosphor Bronze
- Insulation Resistance
- 5000000000Ohm
- Montaj
- Free Hanging
- RoHS Durumu
- ROHS3 Compliant
- Contact Type
- Signal
- Gender
- Male
- Ambalaj
- Bulk
- Seri
- CWR
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2002
- Total Number Of Contacts
- 37
- Plating Thickness
- 10μin
- Genişlik
- 12.5mm
- Flammability Rating
- UL94 V-0
- Contact Finish Thickness
- 10.0μin 0.25μm
- Flange Feature
- Housing/Shell (Unthreaded)
- Contact Finish
- Gold
- Wire Gauge
- 28-30 AWG
- Maks. Çalışma Sıcaklığı
- 125°C
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
- Terminal
- IDC, Ribbon Cable
- Pozisyon Sayısı
- 37
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Feed Through, Shielded, Strain Relief
- Connector Style
- D-Sub
- Renk
- Blue
- Shell Material Finish
- Steel, Tin Plated
- Uzunluk
- 69.6mm
- Dielectric Material
- Thermoplastic
- Montaj Tipi
- Free Hanging (In-Line)
- Reference Standard
- UL, CSA
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Receptacle, Male Pins
- Min. Çalışma Sıcaklığı
- -55°C
- Material Flammability Rating
- UL94 V-0
