Adet bazlı fiyat
- 1+ adet$4.76
- 10+ adet$4.49
- 100+ adet$4.24
- 500+ adet$4.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 2002
- Kurşunsuz Kodu
- yes
- Contact Finish Thickness
- 100.0μin 2.54μm
- Flammability Rating
- UL94 V-0
- Genişlik
- 12.5mm
- Contact Finish
- Tin
- Flange Feature
- Housing/Shell (Unthreaded)
- Plating Thickness
- 100μin
- Total Number Of Contacts
- 15
- Mating Contact Pitch
- 0.108 inch
- Shell Size Connector Layout
- 2 DA A
- Rated Current Signal
- 1A
- Ambalaj
- Bulk
- Seri
- CWR
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Free Hanging
- Insulation Resistance
- 5000000000Ohm
- Dielectric Withstanding Voltage
- 500VDC V
- Contact Materials
- Phosphor Bronze
- Body Depth
- 0.81 inch
- Contact Type
- Signal
- Reference Standard
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Dielectric Material
- Thermoplastic
- Connector Type
- Plug, Female Sockets
- Fabrika Tedarik Süresi
- 10 Weeks
- Akım Değeri
- 1A
- Sıra Sayısı
- 2
- Body Breadth
- 0.49 inch
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 26.4mm
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Reliability
- COMMERCIAL
- Terminal
- IDC, Ribbon Cable
- Çalışma Sıcaklığı
- -55°C~125°C
- Wire Gauge
- 28-30 AWG
- Connector Style
- D-Sub
- Özellikler
- Feed Through, Strain Relief
- Renk
- Blue
