Adet bazlı fiyat
- 1+ adet$5.67
- 10+ adet$5.35
- 100+ adet$5.04
- 500+ adet$4.76
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Shape
- Circular
- Insulation Height
- 0.291 7.40mm
- HTS Kodu
- 8536.69.40.40
- Seri
- CWN
- Contact Type
- Male Pin
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Contact Length Post
- 0.610 15.49mm
- Dielectric Withstanding Voltage
- 500VDC V
- Insulation Resistance
- 5000000000Ohm
- Row Spacing Mating
- 0.100 (2.54mm)
- Additional Feature
- INSERTABLE POLARIZATION
- Insulation Materials
- Thermoplastic
- Current Rating Amps
- 1A
- Pcb Contact Pattern
- RECTANGULAR
- Contact Resistance
- 15mOhm
- Connector Type
- Header
- Number Of Positions Loaded
- All
- Contact Finish Mating
- Gold
- Reference Standard
- UL, CSA
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Pitch Mating
- 0.100 2.54mm
- Parça Durumu
- Active
- Number Of Pcb Rows
- 2
- Mating Contact Pitch
- 0.1 inch
- Insulation Color
- Blue
- Shrouding
- Shrouded - 4 Wall
- Ambalaj
- Bulk
- Polarization Key
- MIL TYP & CENTER
- Mil Conformance
- YES
- RoHS Durumu
- ROHS3 Compliant
- Style
- Board to Cable/Wire
- Contact Materials
- Phosphor Bronze
- Yayın Yılı
- 2013
- Contact Finish Thickness Post
- 50.0μin 1.27μm
- Terminal
- Wire Wrap
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Contact Lengthmating
- 0.240 6.10mm
- Reliability
- MIL-C-83503
- Çalışma Sıcaklığı
- -55°C~125°C
