CES-603318-24PM

Teknik Özellikler

Çalışma Sıcaklığı

-20°C~60°C

Tip

General Purpose

Maks. Oturma Yüksekliği

0.701 17.80mm

Material Magnet

Nd-Fe-B

Nem Hassasiyeti (MSL)

Not Applicable

Ingress Protection

IP66 - Dust Tight, Water Resistant

Port Location

Top

Boyut / Ölçü

2.835Lx1.299W 72.00mmx33.00mm

Power Max

4W

Power Rated

2W

Frequencyselfresonant

800Hz

Material Cone

Polyester, Polyethylene Terephthalate (PET)

Parça Durumu

Active

Efficiency Testing

2W/100mm

Fabrika Tedarik Süresi

5 Weeks

Terminal

Wire Leads

RoHS Durumu

RoHS Compliant

Seri

CES

Efficiency Type

Sound Pressure Level (SPL)

Frequency Range

200Hz~20kHz

Empedans

4Ohm

Efficiency Dba

104.00

Distortion Rating

5% Max @ 1KHz, 0.1M, 1V

Shape

Rectangular
