Adet bazlı fiyat
- 1+ adet$194.10
- 10+ adet$183.11
- 100+ adet$172.75
- 500+ adet$162.97
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Maks. Çalışma Sıcaklığı
- 50°C
- Coilinput Supply Type
- AC/DC
- Number Of Inputs
- 1
- Power Rating
- 3W
- Yükseklik
- 90mm
- Coil Voltagedcmax
- 240 V
- Ihs Manufacturer
- CROUZET LTD
- Package Description
- ROHS COMPLIANT
- Relay Function
- SPDT
- Relay Type
- MONITORING RELAY
- Yayın Yılı
- 2002
- Physical Dimension
- 90mm x 35mm x 65.5mm
- Body Breadth
- 35 mm
- Reach Svhc
- Unknown
- Body Length Or Diameter
- 90 mm
- Contact Voltagedcmax
- 250 V
- Contact Voltageacmax
- 250 V
- Reference Standard
- CE; CSA; IEC; NF; UL
- Onay Kuruluşu
- CE, CSA, UL
- REACH Uyumluluk Kodu
- unknown
- Contact Currentdcmax
- 5A
- HTS Kodu
- 8536.49.00.50
- Yüzey Montaj
- NO
- Operating Temperaturemax
- 50 °C
- Coil Currentdcmax
- 0.013 A
- Üretici Parça No
- 84874320
- Sealing
- IP20; IP30; MOISTURE PROOF
- Ratings
- IP30
- Additional Feature
- COIL POWER AC: 4250 MW
- Coilresistance
- 18461.54 Ω
- Rohs Code
- Yes
- RoHS Durumu
- RoHS Compliant
- Relay Action
- LATCHED
- Operating Temperaturemin
- -20 °C
- Parça Durumu
- Active
- Coil Voltageacmax
- 240 V
- Coil Power
- 3000mW
- Mounting Feature
- DIN-RAIL MOUNT
- Terminal
- Terminal Block
- Body Height
- 65.5 mm
