Adet bazlı fiyat
- 1+ adet$4.75
- 10+ adet$4.48
- 100+ adet$4.23
- 500+ adet$3.99
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Esr Equivalent Series Resistance
- 20mOhm
- Polarity
- Polar
- Surface Mount Land Size
- 0.406Lx0.406W 10.30mmx10.30mm
- Applications
- Automotive, Bypass, Decoupling
- RoHS Durumu
- ROHS3 Compliant
- Ripple Current Low Frequency
- 200mA @ 120Hz
- Ratings
- AEC-Q200
- Packing Method
- TR, 15 INCH
- Fabrika Tedarik Süresi
- 14 Weeks
- Ripple Current
- 200mA
- Terminal Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Boyut / Ölçü
- 0.394Dia 10.00mm
- Kapasitans
- 270μF
- REACH Uyumluluk Kodu
- unknown
- Rated Dc Voltage Urdc
- 35V
- Leakage Current
- 0.0945mA
- Çalışma Sıcaklığı
- -55°C~125°C
- Ripple Current High Frequency
- 2A @ 100kHz
- Terminal Shape
- FLAT
- Maks. Oturma Yüksekliği
- 0.413 10.50mm
- Nominal Gerilim
- 35V
- Size Code
- 4141
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- Tan Delta
- 0.12
- Tip
- Hybrid
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Lifetime Temp
- 4000 Hrs @ 125°C
- Seri
- HZC_V
- Dielectric Material
- ALUMINUM (SOLID POLYMER)
- Life Hours
- 4000 hours
- Kılıf / Paket
- Radial, Can - SMD
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tolerans
- ±20%
