Adet bazlı fiyat
- 1+ adet$1.21
- 10+ adet$1.14
- 100+ adet$1.08
- 500+ adet$1.02
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Esr Equivalent Series Resistance
- 50mOhm
- Polarity
- POLARIZED
- RoHS Durumu
- ROHS3 Compliant
- Ripple Current Low Frequency
- 130mA @ 120Hz
- Surface Mount Land Size
- 0.260Lx0.260W 6.60mmx6.60mm
- Applications
- Automotive, Bypass, Decoupling
- Ripple Current
- 130mA
- Terminal Sayısı
- 2
- Boyut / Ölçü
- 0.248Dia 6.30mm
- Çap
- 6.3mm
- Ratings
- AEC-Q200
- Packing Method
- TR, 15 INCH
- Fabrika Tedarik Süresi
- 14 Weeks
- Terminal
- SMD/SMT
- Yayın Yılı
- 2015
- Kapasitans
- 56μF
- REACH Uyumluluk Kodu
- unknown
- Terminal Shape
- FLAT
- Leakage Current
- 14μA
- Çalışma Sıcaklığı
- -55°C~105°C
- Ripple Current High Frequency
- 1.3A @ 100kHz
- Voltage Rated Dc
- 25V
- Maks. Oturma Yüksekliği
- 0.240 6.10mm
- ECCN Kodu
- EAR99
- Size Code
- 2626
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- Tip
- Hybrid
- Life Hours
- 10000 hours
- Dielectric Material
- ALUMINUM (SOLID POLYMER)
- Seri
- HZA
- Kılıf / Paket
- Radial, Can - SMD
- Tolerans
- ±20%
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dissipation Factor
- 0.14 %
- HTS Kodu
- 8532.22.00.20
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Lifetime Temp
- 10000 Hrs @ 105°C
