Adet bazlı fiyat
- 1+ adet$2.28
- 10+ adet$2.15
- 100+ adet$2.03
- 500+ adet$1.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Applications
- Automotive, Bypass, Decoupling
- Surface Mount Land Size
- 0.209Lx0.209W 5.30mmx5.30mm
- Ripple Current Low Frequency
- 90mA @ 120Hz
- RoHS Durumu
- ROHS3 Compliant
- Esr Equivalent Series Resistance
- 80mOhm
- REACH Uyumluluk Kodu
- unknown
- Kapasitans
- 33μF
- Yayın Yılı
- 2015
- Terminal
- SMD/SMT
- Fabrika Tedarik Süresi
- 14 Weeks
- Ratings
- AEC-Q200
- Çap
- 5mm
- Boyut / Ölçü
- 0.197Dia 5.00mm
- Terminal Sayısı
- 2
- Ripple Current
- 90mA
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount
- ECCN Kodu
- EAR99
- Maks. Oturma Yüksekliği
- 0.240 6.10mm
- Voltage Rated Dc
- 25V
- Ripple Current High Frequency
- 900mA @ 100kHz
- Çalışma Sıcaklığı
- -55°C~105°C
- Leakage Current
- 8.2μA
- Lifetime Temp
- 10000 Hrs @ 105°C
- Parça Durumu
- Active
- Ambalaj
- Tape & Reel (TR)
- Dissipation Factor
- 0.14 %
- Tolerans
- ±20%
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- Radial, Can - SMD
- Life Hours
- 10000 hours
- Dielectric Material
- ALUMINUM (SOLID POLYMER)
- Seri
- HZA
- Tip
- Hybrid
