AFK476M16D16T-F

Teknik Özellikler

ECCN Kodu

EAR99

Genişlik

6.6mm

Kurşunsuz

Lead Free

Ambalaj

Tape & Reel (TR)

Ratings

AEC-Q200

Lifetime Temp

2000 Hrs @ 105°C

Surface Mount Land Size

0.260Lx0.307W 6.60mmx7.80mm

Lead Pitch

1.8mm

Montaj Tipi

Surface Mount

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ripple Current

240mA

Terminal Shape

FLAT

Polarization

Polar

JESD-609 Kodu

e6

Ripple Current Ac

240mA

Esr Equivalent Series Resistance

360mOhm @ 100kHz

Yükseklik

7.8mm

Life Hours

2000 hours

Terminal

SMD/SMT

Reach Svhc

Unknown

Dielectric Material

ALUMINUM (WET)

Kapasitans

47μF

Fabrika Tedarik Süresi

20 Weeks

Parça Durumu

Active

Boyut / Ölçü

0.248Dia 6.30mm

Ripple Current High Frequency

240mA @ 100kHz

Empedans

360mOhm

Kurşunsuz Kodu

yes

Çalışma Sıcaklığı

-55°C~105°C

Capacitor Type

ALUMINUM ELECTROLYTIC CAPACITOR

Terminal Sayısı

2

Ripple Current Low Frequency

180mA @ 120Hz

Voltage Rated Dc

16V

Montaj

Surface Mount

Dissipation Factor

0.16 %

Maks. Oturma Yüksekliği

0.240 6.10mm

Çap

6.3mm

Seri

AFK

Tolerans

±20%

Terminal Kaplaması

Tin/Bismuth (Sn/Bi)
