Adet bazlı fiyat
- 1+ adet$15.49
- 10+ adet$14.61
- 100+ adet$13.78
- 500+ adet$13.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Voltage Rated Dc
- 60V
- Terminal Stili
- PC Pin
- Throw Configuration
- SP7T
- Panel Cutout Dimensions
- Circular - 10.20mm Dia
- Montaj
- PCB, Panel, Through Hole
- Operating Force
- 5.099gfm
- Number Of Poles Per Deck
- 1
- Max Voltage Rating Ac
- 60V
- Voltage Rated Ac
- 60V
- Electricallife
- 10000 cycles
- Index Angle
- 30 °
- Parça Durumu
- Active
- Current Rating Amps
- 150mA AC/DC
- Orientation
- Vertical
- Contact Finish
- Silver
- Contact Plating
- Silver
- Montaj Tipi
- Panel Mount, Through Hole
- Yayın Yılı
- 2012
- Actuator Type
- Round (6mm Dia), Slotted
- RoHS Durumu
- ROHS3 Compliant
- Pozisyon Sayısı
- 7
- Actuator Material
- Polysulfon, Thermoplastic
- Terminal
- PC Pin
- Index Stops
- Fixed
- Life Cycles
- 10000 cycles
- Min. Çalışma Sıcaklığı
- -20°C
- Seri
- RTA
- Circuit Per Deck
- SP7T
- Contact Materials
- Brass
- Angle Of Throw
- 30°
- Depth Behind Panel
- 12.60mm
- Housing Material
- Thermoplastic
- Fabrika Tedarik Süresi
- 10 Weeks
- Actuator Length
- 25.00mm
- Maks. Çalışma Sıcaklığı
- 70°C
- Contact Timing
- Non-Shorting (BBM)
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
