Adet bazlı fiyat
- 1+ adet$4.67
- 10+ adet$4.41
- 100+ adet$4.16
- 500+ adet$3.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Voltage Rating Ac
- 32V
- Actuator Type
- Standard
- Uzunluk
- 7.57mm
- Illumination
- Non-Illuminated
- Maks. Çalışma Sıcaklığı
- 90°C
- Min. Çalışma Sıcaklığı
- -40°C
- Çalışma Sıcaklığı
- -40°C~90°C
- Orientation
- Right Angle
- Kurşunsuz
- Lead Free
- Özellikler
- Sealed
- Switch Function
- Off-Mom
- Voltage Rated Dc
- 32V
- Contact Materials
- Silver
- Mechanical Life
- 100,000 Cycles
- Parça Durumu
- Active
- Voltage Rated Ac
- 32V
- Contact Rating Voltage
- 1VA @ 32VAC/DC
- Ambalaj
- Tape & Reel (TR)
- Terminal
- Gull Wing
- Outline
- 6.38mm x 6.22mm
- Fabrika Tedarik Süresi
- 9 Weeks
- Max Voltage Rating Dc
- 32V
- Circuit
- SPST-NO
- Actuator Orientation
- Top Actuated
- Montaj Tipi
- Surface Mount
- Throw Configuration
- SPST
- Electricallife
- 100000 cycles
- Ingress Protection
- IP57 - Dust Protected, Waterproof
- Operating Force
- 300gf
- Seri
- KT
- RoHS Durumu
- ROHS3 Compliant
- Actuator Height Off Pcb Vertical
- 6.96mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Plating
- Silver
- Power Rating
- 1W
- Yayın Yılı
- 2006
- Actuator Material
- Polyamide (PA), Nylon
- Illumination Type
- Non-Illuminated
- Terminal Stili
- Gull Wing
- Ratings
- IP57, Waterproof
