Adet bazlı fiyat
- 1+ adet$1.80
- 10+ adet$1.70
- 100+ adet$1.60
- 500+ adet$1.51
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Voltage Rated Ac
- 32V
- Outline
- 6.38mm x 6.22mm
- Terminal
- Gull Wing
- Ambalaj
- Tape & Reel (TR)
- Contact Rating Voltage
- 1VA @ 32VAC/DC
- Fabrika Tedarik Süresi
- 9 Weeks
- Max Voltage Rating Ac
- 32V
- Actuator Type
- Standard
- Uzunluk
- 7.57mm
- Illumination
- Non-Illuminated
- Çalışma Sıcaklığı
- -40°C~90°C
- Voltage Rated Dc
- 32V
- Switch Function
- Off-Mom
- Özellikler
- Sealed
- Kurşunsuz
- Lead Free
- Orientation
- Right Angle
- Contact Materials
- Silver
- Mechanical Life
- 100,000 Cycles
- Power Rating
- 1W
- Yayın Yılı
- 2006
- Actuator Material
- Polyamide (PA), Nylon
- Terminal Stili
- Gull Wing
- Ratings
- IP57, Waterproof
- Montaj
- Surface Mount
- Max Voltage Rating Dc
- 32V
- Circuit
- SPST-NO
- Actuator Orientation
- Top Actuated
- Montaj Tipi
- Surface Mount
- Throw Configuration
- SPST
- Actuator Length
- 2.36mm
- Electricallife
- 100000 cycles
- Ingress Protection
- IP57 - Dust Protected, Waterproof
- Operating Force
- 300gf
- Seri
- KT
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Height Off Pcb Vertical
- 5.36mm
- Radyasyon Dayanımı
- No
