Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Illumination Type
- Illuminated, Non-Illuminated
- Actuator Height Off Pcb Vertical
- 4.70mm
- Max Voltage Rating Dc
- 32V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Parça Durumu
- Active
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 10mA
- Mechanical Life
- 1,000,000 Cycles
- Circuit
- SPST-NO
- Fabrika Tedarik Süresi
- 16 Weeks
- Contact Materials
- Gold
- Yayın Yılı
- 2011
- Operating Force
- 130gf
- RoHS Durumu
- ROHS3 Compliant
- Switch Travel
- 0.50mm
- Contact Plating
- Gold
- Contact Rating Voltage
- 0.01A @ 32VDC
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Dc
- 32V
- Seri
- KSA MKII
- Montaj Tipi
- Through Hole
- Actuator Length
- 1mm
- Çalışma Sıcaklığı
- -40°C~125°C
- Switch Function
- Off-Mom
- Outline
- 6.20mm x 6.20mm
- Throw Configuration
- SPST
- Terminal Stili
- PC Pin
- Orientation
- Straight
- Ambalaj
- Bulk
- Uzunluk
- 6.2mm
- Yükseklik
- 4.7mm
- Contact Resistance
- 100mOhm
- Montaj
- Through Hole
- Contact Current Rating
- 10mA
- Illumination
- Non-Illuminated
- Life Cycles
- 1e+06 cycles
- Min. Çalışma Sıcaklığı
- -40°C
- Actuator Orientation
- Top Actuated
- Terminal
- PC Pin
