Teknik Özellikler
- Switch Function
- On-Mom
- Actuator Length
- 4mm
- Reach Svhc
- No SVHC
- Parça Durumu
- Active
- Max Current Rating
- 100mA
- Akım Değeri
- 100mA
- Power Rating
- 1W
- Actuator Type
- Translucent
- Uzunluk
- 8mm
- Montaj Tipi
- Through Hole, Right Angle
- Fabrika Tedarik Süresi
- 11 Weeks
- Mechanical Life
- 25,000 Cycles
- Switch Travel
- 1.20mm
- Contact Resistance
- 150mOhm
- Operating Force
- 400gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Tactile Feedback
- Renk
- Green
- Circuit
- SPDT
- Çalışma Sıcaklığı
- -40°C~85°C
- Actuator Length Right Angle
- 12.40mm
- Actuator Orientation
- Side Actuated
- Kurşunsuz
- Lead Free
- Terminal
- PC Pins
- Contact Rating Voltage
- 0.1A @ 32VDC
- Illumination
- Illuminated
- Housing Material
- Thermoplastic
- Flammability Rating
- UL94 HB
- Genişlik
- 8mm
- Throw Configuration
- SPDT, SPST
- Voltage Rated Dc
- 32V
- Yayın Yılı
- 2006
- Contact Materials
- Gold
- Insulation Resistance
- 1GOhm
- Montaj
- Through Hole
- Contact Current Rating
- 100mA
- RoHS Durumu
- ROHS3 Compliant
- Radyasyon Dayanımı
- No
- Ingress Protection
- IP40
- Depth
- 17.1mm
