Adet bazlı fiyat
- 1+ adet$9.32
- 10+ adet$8.79
- 100+ adet$8.29
- 500+ adet$7.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Dc
- 20V
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Power Rating
- 400mW
- Illumination
- Non-Illuminated
- Orientation
- Straight
- Fabrika Tedarik Süresi
- 14 Weeks
- Kurşunsuz
- Lead Free
- Housing Material
- Stainless Steel
- Özellikler
- Epoxy Sealed Terminals
- Max Voltage Rating Dc
- 20V
- Montaj Tipi
- Panel Mount
- Electricallife
- 100,000 Cycles
- Reach Svhc
- No SVHC
- Switch Function
- On-On
- Yükseklik
- 12.7mm
- Actuator Material
- Brass, Chrome Plated
- Uzunluk
- 12.7mm
- Throw Configuration
- SP, SPDT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Radyasyon Dayanımı
- No
- Contact Materials
- Gold
- Max Voltage Rating Ac
- 20V
- Contact Resistance
- 10mOhm
- Yayın Yılı
- 2003
- Pozisyon Sayısı
- 2
- Genişlik
- 6.86mm
- Illumination Type
- Illuminated, Non-Illuminated
- Terminal Stili
- Solder Lug
- Current Rating Amps
- 0.4VA AC/DC
- Actuator Type
- Standard Round
- Parça Durumu
- Active
- Depth
- 6.86mm
- Terminal
- Solder
- Number Of Poles
- 1
- Montaj
- Panel
- Voltage Rated Ac
- 20V
- Seri
- 7000
- Actuator Length
- 10.67mm
