Adet bazlı fiyat
- 1+ adet$15.96
- 10+ adet$15.05
- 100+ adet$14.20
- 500+ adet$13.40
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mounting Feature
- Flange
- Fabrika Tedarik Süresi
- 8 Weeks
- Nominal Gerilim
- 335V
- ECCN Kodu
- EAR99
- Polarity
- Standard
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Number Of Ports
- 1
- Din Conformance
- NO
- Montaj Tipi
- Panel Mount
- Gender
- Female
- Filter Feature
- NO
- Option
- GENERAL PURPOSE
- Connector Style
- SMA
- Iec Conformance
- NO
- Mating Cycles
- 500
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Connector Type
- Jack, Female Socket
- Mil Conformance
- NO
- Radyasyon Dayanımı
- No
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- JESD-609 Kodu
- e4
- Insulation Resistance
- 5GOhm
- Insulation Materials
- PTFE FLUOROCARBON/PFA
- Center Contact Plating
- Gold
- Empedans
- 50Ohm
- Center Contact Material
- Beryllium Copper
- Fastening Type
- Threaded
- Frekans
- 26.5GHz
- Terminal
- Solder
- Kurşunsuz
- Lead Free
- Bodyshell Style
- RECEPTACLE
- Shield Termination
- Screw
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Copper
- Body Material
- Brass
- Yayın Yılı
- 2002
- Contact Termination
- Compression
- Özellikler
- EMI/RFI Gasket, Field Replaceable, For Hermetically Sealed Pin
