Adet bazlı fiyat
- 1+ adet$6.26
- 10+ adet$5.90
- 100+ adet$5.57
- 500+ adet$5.25
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Copper
- Frekans
- 18GHz
- Bodyshell Style
- RECEPTACLE
- Çalışma Sıcaklığı
- -65°C~165°C
- Montaj
- Bulkhead, Edge, Panel
- Body Material
- Brass
- Yayın Yılı
- 2002
- Contact Termination
- Solder
- Orientation
- Straight
- JESD-609 Kodu
- e4
- Contact Style
- COAX
- Contact Resistance
- 3mOhm
- RoHS Durumu
- RoHS Compliant
- Empedans
- 50Ohm
- Fastening Type
- Threaded
- Center Contact Material
- Beryllium Copper
- Center Contact Plating
- Gold
- Insulation Materials
- PTFE FLUOROCARBON
- Body Length Or Diameter
- 0.375 inch
- Filter Feature
- NO
- Total Number Of Contacts
- 1
- Gender
- Female
- Body Depth
- 0.5 inch
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Connector Type
- Jack, Female Socket
- Mating Cycles
- 500
- Option
- GENERAL PURPOSE
- Connector Style
- SMA
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- Mounting Feature
- Bulkhead - Front Side Nut
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 335V
- Fabrika Tedarik Süresi
- 8 Weeks
- Number Of Ports
- 1
- Montaj Tipi
- Board Edge, End Launch; Panel Mount
- Termination Type
- SURFACE MOUNT
- Ambalaj
- Bulk
- Parça Durumu
- Active
