0ZCD0185FF2C

Teknik Özellikler

Thermistor Application

TEMPERATURE SENSING

Terminal Placement

DUAL ENDED

Hold Current

1.85A

Max Current Rating

40A

Seri

0ZCD

Resistance Initial Ri Min

40mOhm

Case Code Imperial

2920

Maks. Kalınlık

0.035 0.90mm

Montaj Tipi

Surface Mount

Tip

Polymeric

Power Dissipation

1.5W

Contact Plating

Tin

JESD-609 Kodu

e3

RoHS Durumu

ROHS3 Compliant

Terminal Sayısı

2

Kılıf / Paket

2920 (7351 Metric)

Packing Method

TR, 7 INCH

Onay Kuruluşu

cURus, TUV

Çalışma Sıcaklığı

-40°C~85°C

Time To Trip

2.5s

Terminal Shape

WRAPAROUND

Nem Hassasiyeti (MSL)

2A (4 Weeks)

Ambalaj

Tape & Reel (TR)

Physical Dimension

7.98mm x 5.44mm x 0.9mm

Resistance Post Trip R1 Max

150mOhm

Trip Current

3.7A

Case Code Metric

7351

Boyut / Ölçü

0.290Lx0.202W 7.36mmx5.12mm

Working Voltage

33V

Voltage Max

33V

Montaj

Surface Mount

Parça Durumu

Obsolete
