Adet bazlı fiyat
- 1+ adet$5.81
- 10+ adet$5.49
- 100+ adet$5.18
- 500+ adet$4.88
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Cores Per Jack
- 8
- Height Above Board
- 0.536 13.61mm
- Orientation
- 90° Angle (Right)
- Özellikler
- Board Guide
- Mil Conformance
- NO
- Shielding
- Shielded, EMI Finger
- Connector Type
- RJ45
- Çalışma Sıcaklığı
- 0°C~70°C
- Contact Materials
- Copper Alloy
- Gender
- Female
- Nem Hassasiyeti (MSL)
- Not Applicable
- Seri
- MagJack®
- Total Number Of Contacts
- 8
- Montaj Tipi
- Through Hole
- Ul Flammability Code
- 94V-0
- Din Conformance
- NO
- Montaj
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Number Of Ports
- 1
- Ambalaj
- Tray
- Tab Direction
- Up
- Applications
- 10/100/1000 Base-T, AutoMDIX
- Renk
- Green, Yellow
- Empty Shell
- NO
- Filter Feature
- YES
- Pitch
- 2.54mm
- Fabrika Tedarik Süresi
- 14 Weeks
- Iec Conformance
- NO
- Housing Material
- Polyamide (PA46), Nylon 4/6
- Mixed Contacts
- NO
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Led Color
- Green, Yellow - Green
- Shield Material
- Copper Alloy
- Parça Durumu
- Active
- Contact Finish Thickness
- 50.0μin 1.27μm
- Shell Finish
- NICKEL
- Option
- GENERAL PURPOSE
- Contact Finish
- Gold
