9L28050 008H100

Teknik Özellikler

Nem Hassasiyeti (MSL)

Not Applicable

Fabrika Tedarik Süresi

6 Weeks

Uzunluk

100.0' 30.48m

Ribbon Thickness

0.035 0.89mm

Cable Types

Flat Cable

Gerilim

300V

First Conductor Mark

Red

Current Rating Amps

1A

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Conductor Material

Copper, Tinned

Number Of Conductors

50

Shielding

Unshielded

Ribbon Width

2.500 63.50mm

Insulation Resistance

10GOhm

Wire Gauge

28 AWG

Conductor Strand

7 Strands / 36 AWG

Connector Support Type

WIRE AND CABLE

Çalışma Sıcaklığı

-40°C~105°C

Yayın Yılı

2008

Parça Durumu

Active

Pitch

0.050 1.27mm

Jacket Color

Gray

RoHS Durumu

ROHS3 Compliant

Seri

9L280XX

Ratings

UL Style 2651
