208457048001025

Teknik Özellikler

Contact Materials

Bronze

Insulation Resistance

5000000000Ohm

Seri

8457

Contact Finish

Gold

Pitch

0.100 2.54mm

Montaj

Through Hole

Pcb Contact Pattern

RECTANGULAR

Dielectric Withstanding Voltage

1000VAC V

Max Current Rating

3A

Material Flammability Rating

UL94 V-0

Uzunluk

54.89mm

Connector Type

Receptacle, Female Sockets

Current Rating Amps

3A

Ul Flammability Code

94V-0

Ambalaj

Bulk

Reference Standard

UL

Body Orientation

Straight

Kurşunsuz

Lead Free

Reliability

COMMERCIAL

Total Number Of Contacts

48

Material Insulation

Polyester Thermoplastic, Glass Filled

Option

GENERAL PURPOSE

Akım Değeri

3A

ECCN Kodu

EAR99

Level Class

2

Terminal

Solder

Termination Method

Solder

Iec Conformance

NO

Montaj Tipi

Through Hole

Housing Material

Polyester

Paket

Bulk

Contact Resistance

20mOhm

Ürün Durumu

Active

Number Of Positions Loaded

All

Mil Conformance

NO

Name Of Rows Loaded

A,B,C

RoHS Durumu

ROHS3 Compliant

Mounting

Through Hole

Tip

DIN 41612

Fabrika Tedarik Süresi

14 Weeks
