208457032001025

Teknik Özellikler

Filter Feature

NO

Sıra Sayısı

2

Çalışma Sıcaklığı

-65°C~125°C

Orientation

Straight

Style

B/2 (1/2 B)

Basehousing Material

Polyester

Nem Hassasiyeti (MSL)

1 (Unlimited)

Insertion Forcemax

.834 N

Product Length

54.91 mm

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Din Conformance

YES

Yayın Yılı

2008

Rated Current Signal

3A

Depth

8mm

Durability

400 Cycles

Flammability Rating

UL94 V-0

Pozisyon Sayısı

32

Mixed Contacts

NO

Kurşunsuz Kodu

yes

Polarization Key

ENDS

Body Breadth

0.315 inch

Parça Durumu

Active

Gender

Receptacle

Number Of Pcb Rows

2

Mating Contact Row Spacing

0.1 inch

Mil Conformance

NO

HTS Kodu

8536.69.40.40

Tip

DIN 41612

Fabrika Tedarik Süresi

14 Weeks

RoHS Durumu

ROHS3 Compliant

Mounting

Through Hole

Name Of Rows Loaded

A,B

Ürün Durumu

Active

Number Of Positions Loaded

All

Terminal

Solder

Termination Method

Solder

Iec Conformance

NO

Paket

Bulk

Contact Resistance

20mOhm

Housing Material

Polyester
