009296004553906

Teknik Özellikler

Voltage Rating

200 V

Maks. Çalışma Sıcaklığı

125°C

Reference Standard

UL

Pozisyon Sayısı

4

Fabrika Paket Adedi

400

Contact Plating

Tin

Moisture Sensitive

Yes

Min. Çalışma Sıcaklığı

-40°C

Mounting Angle

Straight

Minimum Operating Temperature

- 40 C

Durability

5 Cycles

Boardside Pitch

0.157 4.00mm

Contact Materials

Copper Alloy

Housing Color

White

Applications

Wire-to-Board

Number Of Positions Loaded

All

Tip

Poke-Home

Connector Type

Individual Wires

Wire Gauge Min

18 AWG

Renk

White

Ambalaj

Tape & Reel (TR)

Birim Ağırlık

0.036917 oz

Wire Gauge

18-26 AWG

Number Of Pcb Rows

2

Paket

Bulk

Contact Pattern

RECTANGULAR

Sıra Sayısı

1

Nominal Gerilim

200V

Number Of Conductors

ONE

Cable Pitch

0.157 4.00mm

Akım Değeri

7A

Cable Termination

Poke-In

Pitch

4mm

Nem Hassasiyeti (MSL)

3 (168 Hours)

Body Length Or Diameter

0.63 inch

Terminal

SMD/SMT

Total Number Of Contacts

4

Tradename

Poke Home

Flammability Rating

UL94 V-0

Housing Material

Nylon
