AWLP 20/3,2-G

Teknik Özellikler

Length Termination

0.134 inch

Cable Pitch

0.050 1.27mm

Pcb Contact Pattern

RECTANGULAR

Fabrika Tedarik Süresi

23 Weeks

Contact Pattern

RECTANGULAR

Insulation Materials

GLASS FILLED POLYBUTYLENE TEREPHTHALATE

Operating Temperature Max

105°C

Contact Finish

Gold

Mounting Option2

LOCKING

Renk

Gray

Contact Gender

MALE

Number Of Positions Loaded

All

Reference Standard

UL

Insulation Resistance

1000000000Ohm

Boardside Pitch

0.100 2.54mm

Ambalaj

Tray

Dielectric Withstanding Voltage

500VAC V

Montaj Tipi

Through Hole

Plating Thickness

30μin

Cable Termination

IDC

Nem Hassasiyeti (MSL)

1 (Unlimited)

Mounting Option1

LATCH

RoHS Durumu

ROHS3 Compliant

Pozisyon Sayısı

20

Number Of Conductors

ONE

Polarization Key

POLARIZED HOUSING

Sıra Sayısı

2

Termination Type

SOLDER

Contact Style

RND PIN-SKT

Rated Current Signal

1A

Row Spacing

0.100 (2.54mm)

Operating Temperature Min

-55°C

Connector Type

Ribbon Cable, DIP Header

Total Number Of Contacts

20

Parça Durumu

Active

Özellikler

Feed Through

Number Of Pcb Rows

2

Mating Contact Pitch

0.1 inch

Reliability

COMMERCIAL
