Teknik Özellikler
- Contact Style
- USB, SER B SQ
- Özellikler
- Board Lock
- Polarization Key
- POLARIZED HOUSING
- Mounting Feature
- Horizontal
- Shellshielding Material
- Brass
- Montaj Tipi
- Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Gender
- Receptacle
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bodyshell Style
- PLUG
- Terminal
- Solder
- Shell Finish
- NICKEL
- Ambalaj
- Tray
- Number Of Conductors
- ONE
- Plating Thickness
- FLASH inch
- Kurşunsuz
- Lead Free
- Number Of Contacts
- 9
- Contact Resistance
- 30mOhm
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2011
- Specifications
- USB 3.0 (USB 3.1 Gen 1, Superspeed)
- Connector Type
- USB-B (USB TYPE-B)
- Number Of Ports
- 1
- Current Rating Amps
- 1.5A
- Number Of Pcb Rows
- 3
- Mating Cycles
- 5000
- Reference Standard
- UL
- Contact Finish
- Gold
- Body Breadth
- 0.508 inch
- Body Depth
- 0.72 inch
- Body Length Or Diameter
- 0.508 inch
- Montaj
- Horizontal, Through Hole
- Çalışma Sıcaklığı
- -55°C~85°C
- Dielectric Withstanding Voltage
- 700VAC V
- Reliability
- COMMERCIAL
- Parça Durumu
- Obsolete
- Insulation Color
- Blue
