Adet bazlı fiyat
- 1+ adet$1.94
- 10+ adet$1.83
- 100+ adet$1.72
- 500+ adet$1.63
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Dielectric Withstanding Voltage
- 500VAC V
- Length Termination
- 0.098 inch
- Specifications
- USB 2.0
- Mating Cycles
- 1500
- Ambalaj
- Tray
- Material Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Contact Style
- USB, SER A FLAT
- Number Of Contacts
- 4
- Contact Finish
- Gold
- Özellikler
- Board Lock
- Insulation Materials
- POLYBUTYLENE TEREPHTHALATE
- Body Breadth
- 0.299 inch
- Connector Type
- USB-A (USB TYPE-A)
- Montaj Tipi
- Through Hole, Right Angle
- Çalışma Sıcaklığı
- -55°C~85°C
- Parça Durumu
- Active
- Gender
- Receptacle
- Mounting Feature
- Vertical
- Pcb Contact Pattern
- RECTANGULAR
- Polarization Key
- POLARIZED HOUSING
- Reference Standard
- UL,VDE
- Number Of Pcb Rows
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mounting Option1
- DETENT
- Additional Feature
- SIDE ENTRY, SHORT VERSION
- Shell Finish
- NICKEL
- JESD-609 Kodu
- e3
- Yayın Yılı
- 2013
- Fabrika Tedarik Süresi
- 23 Weeks
- Insulation Color
- White
- Terminal
- Solder
- Contact Materials
- PHOSPHOR BRONZE
- RoHS Durumu
- ROHS3 Compliant
- Mounting Option2
- LOCKING
- Current Rating Amps
- 1.5A
- Number Of Conductors
- ONE
- Shellshielding Material
- Brass
- Number Of Ports
- 1
- Body Length Or Diameter
- 0.583 inch
