Teknik Özellikler
- Montaj Stili
- RIGHT ANGLE
- Rohscompliant
- Yes
- Contact Materials
- PHOSPHOR BRONZE
- Body Length
- 0.594 inch
- Mounting Option2
- LOCKING
- Manufacturer Series
- A-USB
- Ihs Manufacturer
- ASSMANN ELECTRONICS INC
- Rated Current Signal
- 1.5 A
- Terminal Length
- 0.11 inch
- REACH Uyumluluk Kodu
- compliant
- Shell Finish
- NICKEL
- Number Of Connectors
- TWO
- Board Mounting Option
- SOLDERABLE RETENTION CLIPS
- Total Number Of Contacts
- 8
- Mounting Option1
- DETENT
- Number Of Pcb Rows
- 1+1
- Pcb Contact Pattern
- RECTANGULAR
- Polarization Key
- POLARIZED HOUSING
- Reference Standard
- UL,VDE
- Termination Type
- SOLDER
- Contact Gender
- MALE
- Body Breadth
- 0.634 inch
- Content
- 1pc(s)
- Connector Standard
- USB 2.0
- Connector Type
- Socket, built-in
- Montaj Tipi
- BOARD
- Part Life Cycle Code
- Contact Manufacturer
- Shell Material
- BRASS
- Üretici Parça No
- A-USB-A-2P
- Reliability
- COMMERCIAL
- Connections
- Soldering
- Contact Style
- USB, SER A FLAT
- Rohs Code
- Yes
- Body Depth
- 0.669 inch
- Bodyshell Style
- RECEPTACLE
- Insulator Material
- POLYBUTYLENE TEREPHTHALATE
- Risk Rank
- 5.68
- Insulation Resistance
- 1000000000 Ω
- Manufacturer Part
- A-USB A-2P
- Tip
- USB A
