Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Length Or Diameter
- 0.283 inch
- Number Of Ports
- 1
- Number Of Conductors
- ONE
- Shellshielding Material
- Brass
- Contact Materials
- Bronze
- Housing Material
- Polybutylene
- RoHS Durumu
- RoHS Compliant
- Terminal
- Solder
- Insulation Color
- White
- Yayın Yılı
- 2009
- Shell Finish
- NICKEL
- Montaj
- Through Hole, Vertical
- Number Of Pcb Rows
- 4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pcb Contact Row Spacing
- 2.0066 mm
- Reference Standard
- UL
- Pcb Contact Pattern
- RECTANGULAR
- Mounting Feature
- Vertical
- Parça Durumu
- Obsolete
- Gender
- Receptacle
- Montaj Tipi
- Through Hole, Right Angle
- Çalışma Sıcaklığı
- -55°C~85°C
- Body Breadth
- 0.567 inch
- Connector Type
- USB-A (USB TYPE-A)
- Özellikler
- Board Lock
- Kurşunsuz
- Lead Free
- Pitch
- 5.08mm
- Contact Style
- USB, SER A FLAT
- Orientation
- Right Angle
- Number Of Contacts
- 4
- Contact Finish
- Gold
- Reliability
- COMMERCIAL
- Max Current Rating
- 1.5A
- Body Depth
- 0.758 inch
- Ambalaj
- Tray
- Mating Cycles
- 1500
- Material Flammability Rating
- UL94 V-0
- Specifications
- USB 2.0
- Contact Resistance
- 30mOhm
- Dielectric Withstanding Voltage
- 750VAC V
