Adet bazlı fiyat
- 1+ adet$1.17
- 10+ adet$1.10
- 100+ adet$1.04
- 500+ adet$0.98
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish
- Tin
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Termination Type
- SOLDER
- Cable Termination
- IDC
- Operating Temperature Max
- 105°C
- HTS Kodu
- 8536.69.40.40
- Fabrika Tedarik Süresi
- 23 Weeks
- Mating Contact Pitch
- 0.1 inch
- ECCN Kodu
- EAR99
- Body Length Or Diameter
- 1.004 inch
- Reference Standard
- UL
- Dielectric Withstanding Voltage
- 500VAC V
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 2
- RoHS Durumu
- ROHS3 Compliant
- Additional Feature
- ROHS COMPLIANT
- Insulation Resistance
- 1000000000Ohm
- Number Of Conductors
- ONE
- Contact Materials
- BRASS
- Contact Pattern
- RECTANGULAR
- Contact Gender
- MALE
- Ambalaj
- Tray
- Contact Style
- IDC
- Total Number Of Contacts
- 16
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Feed Through
- Row Spacing
- 0.300 (7.62mm)
- Body Breadth
- 0.417 inch
- Bodyshell Style
- RECEPTACLE
- Mounting Option1
- LOCKING
- Renk
- Black
- Pozisyon Sayısı
- 16
- Number Of Pcb Rows
- 2
- Connector Type
- Ribbon Cable, DIP Header
- Reliability
- COMMERCIAL
- Cable Pitch
- 0.050 1.27mm
- Length Termination
- 0.134 inch
- Boardside Pitch
- 0.100 2.54mm
