DS40

Teknik Özellikler

Terminal Material

BRASS

Mounting Feature

THROUGH HOLE-STRAIGHT

Yüzey Montaj

NO

Parça Durumu

Obsolete

Insulation Resistance

1000000000Ohm

Length Termination

0.118 inch

Pcb Hole Count

6

Additional Feature

UL94V-0 MATERIALS USED

End Contact Material

BRASS

Switch Action

MAINTAINED

Switch Function

3PST

Solderability

WAVE

Insulation Materials

POLYAMIDE

Body Length Or Diameter

9.1948mm

Body Height

7.6962mm

Contact Voltagedcmax

24V

Pozisyon Sayısı

1

Electricallife

2000 Cycle(s)

Operating Temperature Max

70°C

End Contact Plating

SILVER OVER NICKEL

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Resistance

0.05mOhm

Body Breadth

9.6774 mm

Actuator Material

POLYAMIDE

REACH Uyumluluk Kodu

compliant

Contact Dc Max Rating R Load

0.025A@24VDC

Tip

Lead Free

Center Contact Material

BRASS

Sealing

EPOXY

Contact Function

ON-OFF

Operating Temperature Min

-25°C

Center Contact Plating

GOLD OVER NICKEL

Washability

ULTRASONIC

Dielectric Withstanding Voltage

500VDC V

Contact Currentdcmax

0.025A

Terminal Kaplaması

SILVER/NICKEL
