Adet bazlı fiyat
- 1+ adet$23.99
- 10+ adet$22.63
- 100+ adet$21.35
- 500+ adet$20.14
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -40°C~125°C
- Voltage Rated Dc
- 50V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Panel Cutout Dimensions
- Circular - 13.60mm Dia
- Özellikler
- Tactile Feedback
- Orientation
- Straight
- Voltage Rated Ac
- 48V
- Akım Değeri
- 200mA
- Terminal Stili
- Solder Lug
- Housing Material
- Thermoplastic
- Ratings
- Dust Tight, IP67, Waterproof
- Throw Configuration
- SPST
- Fabrika Tedarik Süresi
- 5 Weeks
- Contact Plating
- Gold
- Actuator Length
- 2mm
- Contact Materials
- Gold, Silver
- Color Actuatorcap
- Red
- Illumination Type Color
- LED, Red
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Max Voltage Rating Dc
- 24V
- Montaj Tipi
- Panel Mount, Front
- Ambalaj
- Bulk
- Illumination Type
- LED
- Montaj
- Front, Panel
- Number Of Poles
- 1
- Contact Current Rating
- 500mA
- Tip
- Standard, Illuminated
- Actuator Type
- Round, Button
- Switch Function
- Off-Mom
- Parça Durumu
- Active
- Seri
- IP
- Circuit
- SPST-NO
- Contact Resistance
- 100mOhm
- Current Rating Amps
- 500mA AC 200mA DC
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Mechanical Life
- 1e+06 cycles
- Actuator Material
- Polyamide
