Adet bazlı fiyat
- 1+ adet$26.32
- 10+ adet$24.83
- 100+ adet$23.42
- 500+ adet$22.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- ROHS3 Compliant
- Contact Dc Max Rating R Load
- 5A@28VDC
- Actuator Material
- Polyamide
- Contact Resistance
- 100mOhm
- Current Rating Amps
- 500mA AC 200mA DC
- Kurşunsuz Kodu
- yes
- Mechanical Life
- 1e+06 cycles
- Tip
- Standard, Illuminated
- Contact Currentdcmax
- 5A
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Actuator Length
- 2mm
- Contact Materials
- Gold, Silver
- Body Height
- 6.4mm
- Throw Configuration
- SPST
- Housing Material
- Thermoplastic
- Contact Voltageacmax
- 48V
- Voltage Rated Ac
- 48V
- Akım Değeri
- 200mA
- Voltage Rated Dc
- 50V
- Electricallife
- 500,000 Cycles
- Illumination Voltage Nominal
- 2VDC
- Parça Durumu
- Active
- Circuit
- SPST-NO
- Seri
- IP
- Kurşunsuz
- Lead Free
- Actuator Type
- Round, Button
- Switch Function
- Off-Mom
- Number Of Poles
- 1
- Contact Current Rating
- 5A
- Illumination Type
- LED
- Montaj
- Front, Panel
- Illumination Type Color
- LED, Green
- Max Voltage Rating Dc
- 24V
- Montaj Tipi
- Panel Mount, Front
- Ambalaj
- Bulk
- Color Actuatorcap
- Black
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 5 Weeks
- Contact Plating
- Gold
