Adet bazlı fiyat
- 1+ adet$9.43
- 10+ adet$8.90
- 100+ adet$8.39
- 500+ adet$7.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Front, Panel
- HTS Kodu
- 8536.50.90.33
- Contact Current Rating
- 5A
- Number Of Poles
- 1
- Contact Currentdcmax
- 1A
- Color Actuatorcap
- Black
- Contact Materials
- Gold, Silver
- Kılıf / Paket
- 125
- Actuator Length
- 2mm
- Montaj Tipi
- Panel Mount, Front
- Ambalaj
- Bulk
- Max Voltage Rating Dc
- 72V
- Terminal
- Solder
- Flammability Rating
- UL94 V-0
- Depth
- 17.5mm
- Actuator Material
- Polyamide
- Electricallife
- 200,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 2A
- Actuator Type
- Round, Button
- Switch Function
- Off-On
- Tip
- Standard
- Kurşunsuz
- Lead Free
- Contact Resistance
- 100mOhm
- Current Rating Amps
- 2A AC 4A DC
- Seri
- IP
- Circuit
- SPST
- Parça Durumu
- Active
- Orientation
- Straight
- Özellikler
- Epoxy Sealed Terminals
- Panel Cutout Dimensions
- Circular - 13.60mm Dia
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Uzunluk
- 17.5mm
- Terminal Stili
- Solder Lug
- Akım Değeri
- 2A
- Voltage Rated Ac
- 125V
- Max Voltage Rating Ac
- 125V
- Çalışma Sıcaklığı
- -40°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
