Adet bazlı fiyat
- 1+ adet$46.49
- 10+ adet$43.86
- 100+ adet$41.38
- 500+ adet$39.03
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Circuit
- SPST-NO
- Actuator Length
- 2mm
- Voltage Rated Ac
- 48V
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Thermoplastic
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Color Actuatorcap
- Red
- Özellikler
- Tactile Feedback
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 5 Weeks
- Montaj Tipi
- Panel Mount, Front
- Actuator Material
- Polyamide
- Actuator Type
- Square, Button
- Seri
- IP
- Akım Değeri
- 200mA
- Current Rating Amps
- 500mA AC 200mA DC
- Voltage Rated Dc
- 50V
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 24V
- Ratings
- Dust Tight, IP67, Waterproof
- Panel Cutout Dimensions
- Circular - 13.60mm Dia
- Contact Plating
- Gold
- Montaj
- Front, Panel
- Contact Resistance
- 100mOhm
- Throw Configuration
- SPST
- Contact Materials
- Gold, Silver
- Tip
- Standard
- Contact Current Rating
- 5A
- Electricallife
- 500,000 Cycles
- Mechanical Life
- 1e+06 cycles
- Ambalaj
- Bulk
- Terminal
- Wire Leads
- Çalışma Sıcaklığı
- -40°C~125°C
- Orientation
- Straight
- Terminal Stili
- Wire Leads
- Flammability Rating
- UL94 V-0
- Switch Function
- Off-Mom
