Adet bazlı fiyat
- 1+ adet$5.95
- 10+ adet$5.61
- 100+ adet$5.30
- 500+ adet$5.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Coupler Type
- Standard
- Coupling Factor
- 3dB
- Maks. Çalışma Sıcaklığı
- 95°C
- Case Code Imperial
- 2520
- Characteristic Impedance
- 50Ohm
- Return Loss
- 24.9dB
- Ambalaj
- Tape & Reel (TR)
- JESD-609 Kodu
- e3
- Frekans
- 800MHz~1GHz
- Terminal Kaplaması
- Tin (Sn)
- Vswrmax
- 1.15
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- Xinger III®
- Yayın Yılı
- 2007
- Applications
- AMPS, CDMA, WCDMA
- Isolation
- 23dB
- Terminal
- SMD/SMT
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 4
- Input Powermax Cw
- 52.72dBm
- Rfmicrowave Device Type
- 90 DEGREE HYBRID COUPLER
- Additional Feature
- HIGH ISOLATION
- Insertion Loss Db
- 0.2 dB
- Case Code Metric
- 6450
- Fabrika Tedarik Süresi
- 12 Weeks
- Min. Çalışma Sıcaklığı
- -55°C
- Construction
- COMPONENT
- Max Power Dissipation
- 187W
- Kılıf / Paket
- 2520 (6450 Metric)
