AMIF100S201

Teknik Özellikler

Input Capacitance Ciss Max Vds

5720 pF @ 15 V

Current Continuous Drain Id25

200A (Tc)

Power Dissipation Max

300W (Tc)

Drain To Source Voltage Vdss

100 V

Parça Durumu

Active

Tedarikçi Cihaz Paketi

TO-263

Vgsth Max Id

1V @ 250µA

Fet Type

N-Channel

Vgs Max

±20V

Ambalaj

Bulk

Montaj Tipi

Surface Mount

Çalışma Sıcaklığı

-55°C ~ 175°C (TJ)

Kılıf / Paket

TO-263-3, D2PAK (2 Leads + Tab), TO-263AB

Rds On Max Id Vgs

4mOhm @ 45A, 10V

Gate Charge Qg Max Vgs

66 nC @ 4.5 V

Drive Voltage Max Rds On Min Rds On

10V
